FHF Ex FernTel 3 Zone 2

1.206,66 € – 1.236,41 € INCL. VAT

The Explosion-proof FernTel 3 Zone 2 / 22 Analog Telephone with spiral/steel armored handset cord is specially designed for use in hazardous areas (zone 2 + 22 with gas and dust), applicable both indoors and outdoors (IP65)(-20°C to +55°C temperature range). It comes with/without an LCD display, has a polycarbonate housing, a call tone of approximately 95 dB(A), and a boostable receiver volume (in only 2 steps); (Ex. protection class: II 3G Ex nA ic IIC T5 Gc / II 3D Ex tc IIIC T80°C Dc).

Description

Product Description

The new Explosion-proof FernTel 3 / Zone 2 from FHF is for use in areas with explosive atmospheres (Zone 2 and 22). Its housing is made of impact-resistant and shockproof Polycarbonate and approved for Zone 2 and 22 according to ATEX. Its striking signal color ensures the FernTel 3 / Zone 2 cannot be missed whenever a telephone is urgently needed. The resistance of housing and the use of screws of stainless steel are especially advantageous for use in areas with high air humidity and explosive atmospheres. This telephone can be mounted to a wall or desk.

Application Example

The new Ex FernTel 3 / Zone 2 is the ideal telephone for many different work areas with explosive atmospheres in Zone 2 and 22.

Features

Protection degree IP 65
Stabiliser bracket (optional)
Ambient temperature -20ºC to +55ºC
Call tone ≥ 95 dB(A), 1 m
Explosion protection class: II 3 G Ex nA L IIC T5 // II 3 D Ex tD A22 IP65 80°C

Product Specifications

Certification
Expl. protection class	II 3 G Ex nA L IIC T5
Expl. protection class	II 3 D Ex tD A22 IP65 80ºC
Net access, Acoustics	TBR 21, TBR 38
Electrical Safety	EN60950
Call tone	≥95 dB(A), 1 m

Ambient conditions
Display	-10ºC to +55ºC
Operating temperature	-20ºC to +55ºC
Transport and storage temperature	-25ºC to +70ºC
Protection degree	IP 65

Connection data
Call frequency programmable	16…68 Hz
Pulse-break ratio programmable	1,5 : 1 60/40 ms
Pulse-break ratio programmable	2 : 1 66.7/33.3 ms
MFV	According to CCITT Q23
Flash time Approx	80 ms, 1 ms…999 ms programmable
Line voltage	24 to 66 VDC

Housing
Height x width x depth Approx:	293 x 191 x 128 mm (Please see downloads for dimensions diagram)
Weight Approx:	2.3 kg
Operating position:	Desktop or vertical wall mounting

Handset
Transmitter capsule:	Electret microphone

Connections
Wire:	Up to 0.25 mm2, wire to 2.5 mm2
Incoming telephone line:	TCP/La, TCP/Lb
Secondary bell:	w1, w

Cable glands
	1 cable gland handset
	1 cable gland M 20 x 1.5
	1 blind plug M20 x 1.5
	2 blind plugs M12 x 1.5

Optional Accessories

This product has a Stabiliser bracket (F11239000) as an accessory.

Guarantee

Manufacturer standard guarantee.

Ordering Information

Type	Name	Handset cord type	Display Version	Color	Article no.
FernTel 3 / Zone 2	Desk/Wall Telephone	spiral cord	without display	black	FHF11240020
				yellow	FHF11240021
				red	FHF11240022
				grey	FHF11240027
			with display	black	FHF11241020
				yellow	FHF11241021
				red	FHF11241022
				grey	FHF11241027
		steel armoured cord	without display	black	FHF11242020
				yellow	FHF11242021
				red	FHF11242022
				grey	FHF11242027
			with display	black	FHF11243020
				yellow	FHF11243021
				red	FHF11243022
				grey	FHF11243027

For ATEX and IECEx units, the full article number is made up by appending the colour code for the coloured housing to the article number given here (-) (Yellow 1 | Red 2 | Grey 7 | Black 0 | For Inmetro certified units please add (45) to the article no.).

ALL PICTURES SHOWN ARE FOR ILLUSTRATION PURPOSE ONLY. ACTUAL PRODUCTS MAY VARY DUE TO PRODUCT ENHANCEMENT.

SKU: FHF-TE03PBX-2011-008 Categories: Field Equipment, PABX, Telecom
