The BAS-IP AV-08FB is an individual entrance panel with face recognition and a multi-language WEB interface.
The BAS-IP AV-08FB Individual Entrance Panel with Face Recognition is a stylish and unique entrance panel with face recognition. This panel has a 2-megapixel camera and a piezoelectric call button. The AV-08FB also has a full-duplex talking mode and 4 polyphonic call melodies, with the ability to customize melodies for different actions. Open Lock by using a monitor, the BAS-IP intercom application, and the API.
| Details | |
| Panel type | Individual |
|---|---|
| Power supply | PoE, +12 В (+8% -4%) |
| Power consumption | 6.5 W, in standby – 3.8 W |
| Installation | Flush mounting, surface with BR-AV8 ONVIF |
| Case | Aluminum alloy |
| Colors | Silver, Black, Gold |
| Dimension of the panel | 95×190×27 mm |
| Installation dimensions | 85×180×45 mm |
| Camera | 1/3” |
| resolution | 2.0 MP |
| Angel | 90° (horizontal) |
| Output video | 1080p (1920×1080), H.264 Main Profile |
| Night backlight | 6 LEDs |
| Light sensitivity | 0.01 Lux |
| Working temperature | -40 to +65 °С |
| Protection class | IP65 |
| Operating humidity | 0% to 86% |
| Storage Humidity | 0% to 60% |
| Call button | Piezoelectric |
| ONVIF | Yes |
| Functionality | |
| Interface | WEB-interface |
|---|---|
| Lock opening | Face Recognition Identification
By means of a monitor By an access card By QR code By guest link From the BAS-IP Intercom application From the BAS-IP UKEY application From API |
| Identifiers in the panel memory | 20,000 |
| Face recognition identifications | 10,000 faces |
| Integration with ACS | Output WIEGAND-26, 32, 34, 37, 40, 42, 56, 58, 64 bit |
| Supported Wiegand types | 26, 32, 34, 37, 40, 42, 56, 58, 64 |
| Number of ringtones | 4 polyphonic ringtones |
| Authentication | Separate password allowing access to the settings for the WEB-interface |
| Talking mode | Duplex |
| Additionally | Built-in relay
Proximity sensor Software Link support SIP P2P Open API Tamper Power supply of the electromechanical lock via PoE 2 separate inputs for door sensors |
