The BAS-IP AV-05FD is an individual entrance panel with a touch-free button and multi-language WEB interface. This device also has full-duplex talking mode and lock opening by using a monitor, the BAS-IP intercom application, and API.
The BAS-IP AV-05FD is Individual entrance panels with cameras and touch-free buttons are stylish vandal-proof panels with installation by the flush method. This individual entrance panel is suitable for installation both in apartments and in the office, factory, gas station, etc.
| Details | |
| Panel type | Individual |
|---|---|
| Display | No |
| resolution | 1.3 Мp |
| Power supply | PoE, +12 V DC (+12% -6%) |
| Power consumption | 6.,5 W, in standby – 3.6 W |
| Installation | Flush mounting |
| Case | Metal alloy |
| Colors | Silver, black, gold, stainless steel |
| Dimension of the panel | 95×190×37 mm |
| Camera | 1/3” |
| Angel | 110° (horizontal) |
| Output video | 720p (1280×720), H.264 Main Profile |
| Night backlight | 6 LEDs |
| Light sensitivity | 0.01 Lux |
| Working temperature | -40 to +65 °С |
| Protection class | IP64 |
| Operating humidity | 0% to 89% |
| Storage humidity | 0% to 60% |
| Functionality | |
| Interface | Multi language, WEB-interface |
|---|---|
| Lock opening | By means of a monitor By QR code By guest link From the BAS-IP Intercom application From API |
| Quick-dial buttons | 1 touchless call button |
| Integration with ACS | Input WIEGAND-26 |
| Authentication | WEB-interface and RTSP stream |
| Talking mode | Duplex |
| Additionally | Built-in relay Software Link support SIP P2P Open API |
