Product Description
The DUST/AD Gas Detector for O2 with Electrochemical Cell is designed and manufactured by Oggioni to measure concentrations of combustible gases in the range of 0-100% Lower Explosive Level (LEL) or O2, in the ppm range, in an atmosphere generally consisting of air.
A modular design of the transmitters allows the usage of sensors in various electrochemical cell technologies. Made with SMT technology, the enose® transmitter is extremely compact and sealed in the detector’s head. It may be used either as an autonomous detecting device featuring electrical controls right next to the sensor, or it may be connected to remote data monitoring systems.
The enose® GM1 Sensor Head is a self-contained microprocessor-controlled device with non-volatile memory that allows for non-intrusive calibration with a magnetic tool by a single person. The air sample to be analyzed enters the head’s measuring chamber, where the sensor is located, by convection and diffusion through a flame arrester, sintered stainless steel filter, or wire mesh screened opening.
Thanks to the introduction of the modbus or Bluetooth protocols, it is now possible to establish direct communication between the sensor and your PC, PDA, or mobile phone. This feature allows you to have complete control of all of the sensor’s functional parameters, such as Zero, Span, Sensitivity, Alarm Thresholds, TWA, STEL, and Download maintenance operations reports or the event log.
Application Example
Ideal to detect combustible gas and solvents, the typical application field of the RAS transmitters are:
- Chemical and petrochemical industries
- Gas treatment, storage and distribution plants
- Combustible material storage
